| 제품명: | 시트 버트 융합 용접 기계 | 전압: | 380V |
|---|---|---|---|
| 빈도: | 50/60Hz | 단계: | 3P |
| 용접 두께: | 3-50 밀리미터 | 길이로 일하는 맥스: | 6000mm |
| 용접 재료: | PP, HDPE, PVC, PVDF | 기능: | 수평 용접, 원형 용접, 90° 수직 2장 용접 |
| 자격증: | CE | 애플리케이션: | 소방차, 수영장, 폐수 처리 등 |
| 강조하다: | 6M HDPE sheet welding machine,butt fusion machine for salmon farming,underwater HDPE tank welding machine |
||
Sheet Butt Fusion Welding Machine Application:
Fire Trucks, Salmon Farming, Acquaculture, Electroplating equipment, environmental protection equipment, chemical containers, sewage treatment, etc
Sheet Butt Fusion Welding Machine Specification:
| Model | SWT-PH6000 |
| Weldable sheet thickness(mm) | 3.0-50.0 |
| Max working length(mm) | 6000 |
| Roll circle diameter minimum(mm) | 600 |
| Air pressure(kg.f/cm²) | 6.0-8.0 |
| Energy source(m³/min) | 0.0032 |
| Rated voltage(V) | 380V |
| Rated current(A) | 23A |
| Heating Power(kW) | 11kW |
| Rolling Motor Power(kW) | 3kW |
Sheet Butt Fusion Welding Machine Features:
Application:
After-Sales Service:
We can provide free training service to our customers at our factory.
We can also provide on-site training to our customers on their request. The accomodation fees will be borne by them.
